SS-1320-NA/SS-1820-NA
UNIFITTING
Description：
It is a kind of stainless steel standoff holder. It's made of high quality 304 grade stainless steel for outdoor use.
Specification:
| Item No. | Color & Material | Diameter | Cap Thickness | Spacer | Screw Pole Size | Bottom Hole Size | Max Panel Thickness | Set Screw |
| SS-1320-NA | Natural | 13mm | 1mm | 20mm | Dia.8mm* L22mm | 4.2mm | 8mm | M4x4 |
| SS-1820-NA | Natural | 18mm | 1mm | 20mm | Dia. 8mm *L22mm | 4.2mm | 8mm | M4x4 |
Description：
It is a kind of stainless steel standoff holder. It's made of high quality 304 grade stainless steel for outdoor use.
Specification:
| Item No. | Color & Material | Diameter | Cap Thickness | Spacer | Screw Pole Size | Bottom Hole Size | Max Panel Thickness | Set Screw |
| SS-1320-NA | Natural | 13mm | 1mm | 20mm | Dia.8mm* L22mm | 4.2mm | 8mm | M4x4 |
| SS-1820-NA | Natural | 18mm | 1mm | 20mm | Dia. 8mm *L22mm | 4.2mm | 8mm | M4x4 |
